Sacem 3" Horizontal Boring Mill
Sacem 3" Horizontal Boring Mill
$24,500 (USD)
Location:Orange City, IA
or
Call 712-737-8700
Description
Equipped with:
Acu-Rite 3 axis DRO
#40NMTB taper and 6 holders
Pendant control
Facing head
Out board support
Specifications
| Manufacturer | Sacem 3" Horizontal Boring Mill |
| Condition | Used |
| Serial Number | S47-010 |
| Stock Number | 10683 |
| Spindle diameter | 3" |
| Spindle taper | NMTB40 |
| Spindle speeds | 7-950 RPM |
| Table size | 43" x 51" |
| Rotation of table | 360 degrees |
| Quill travel | 29-1/2" |
| Longitudinal travel | 51" |
| Cross travel | 51" |
| Vertical column travel | 32" |
| Quill feeds per rev | 1/160th-1-2/3" |
| Vertical feeds | 0.003-7.2" |
| Longitudinal feeds | 0.0015-40" |
| Cross feeds | 0.005-1.25" |
| Facing head feeds | 3.1" - 820" |
| Main motor | 10 HP, 220/440V |
| Estimated weight | 20,000 LBS |
