2011 Ermaksan 121 Ton Hydraulic Ironworker EKM 110-180 (metric tons) US Model: 121-198
2011 Ermaksan 121 Ton Hydraulic Ironworker EKM 110-180 (metric tons) US Model: 121-198
$27,500 (USD)
Never used
Location:Orange City, IA
or
Call 712-737-8700
Description
Equipped with:
2 electric pedals
*Machine was stored but never used.*
Specifications
| Manufacturer | Ermaksan 121 Ton Hydraulic Ironworker |
| Model | EKM 110-180 (metric tons) US Model: 121-198 |
| Year | 2011 |
| Condition | Used |
| Serial Number | 03914-PT2X8F |
| Stock Number | 10931 |
| Punch | 121 Ton |
| Maximum punch capacity, maximum diameter | 1.57" x .079" |
| Maximum thickness | 1.1" x 1.1" |
| Throat depth | 24" |
| Stroke length | 3.15" |
| Cycles per minute | 28 |
| Flat shear maximum thickness | 15.7" x .79" |
| Flat shear maximum width | 23.6" x .59" |
| Flat shear blade length | 24" |
| Angle shear at 90 degrees | 5.9" x 5.9" x .51" |
| Angle shear at 45 degrees | 2.76" x 2.76" x .28" |
| Bar shear round | 1.96" |
| Bar shear square | 1.96" |
| Notching material thickness | 0.51" |
| Rectangle notcher | 2.05" x 3.54" |
| Main motor | 15 HP, 220/440V, 3 PH |
| Machine weight | 3,335 LBS |
| Machine Dimensions | 76" x 99" x 89"H |
