Hyd-Mech V-18APC-60-60 Automatic Vertical Bandsaw V-18APC-60-60
Hyd-Mech V-18APC-60-60 Automatic Vertical Bandsaw V-18APC-60-60
Contact us for price
Location:Canada
Description
Equipped with:
Automatic programmable mitering w/”go to” angle functionality from 60° left to 60° right
8.5” Mitsubishi FX5U PLC color touch screen controller. No flipping from screen to screen, the control is
interactive w/messages for the operator that reduces the learning curve. User friendly graphical icon
programming for miter cutting, 1000 jobs, 20 jobs in queue.
Automatic multi-indexing up to 40” in a single stroke. Powered by rack and pinion servo drive.
Powered movable guide arm
Hydraulic overhead bundling
7.5 HP VFD. True direct blade drive – no belts/pulleys
Hydraulic DDF system
Blade chamber separates material from cut part
Out of stock switch
Cast iron band wheels
Replaceable blade brush
Easy access electrical panel and hydraulics
Blade breakage switch
Drag chain chip conveyor
You choose left or right side infeed
Hydraulic band tensioning w/digital readout
Replaceable carbide guide inserts
2 HP hydraulic pump provides system pressure
Safety door interlocks
Flood coolant w/wash down hose
Work light
Laser light
Variable vise pressure
3° canted head
Optional features for additional cost:
10’ bar feed
Chip bucket
Mist lubrication
Non-driven pop-up lift rollers
Tall square vise inserts
Hydraulic chip conveyor
Idler conveyors and accessories
Power conveyors and accessories
Power transformer
Specifications
| Manufacturer | Hyd-Mech V-18APC-60-60 Automatic Vertical Bandsaw |
| Model | V-18APC-60-60 |
| Condition | New |
| Stock Number | Hyd-Mech V-18APC-60-60 |
| Capacity rectangle @ 90 degrees | 22" x 18" |
| Capacity rectangle @ 90 degrees w/overhead bundling | 12" x 18" |
| Capacity round @ 90 degrees | 18" |
| Capacity round @ 90 degrees w/overhead bundling | 12" |
| Capacity rectangle @ 45 degrees | 14-3/4" x 18" |
| Capacity rectangle @ 45 degrees w/overhead bundling | 12" x 18" |
| Capacity round @ 45 degrees | 13" |
| Capacity round @ 45 degrees w/overhead bundling | 12" |
| Capacity rectangle @ 30 degrees | 9" x 18" |
| Capacity rectangle @ 30 degrees w/overhead bundling | 6" x 18" |
| Capacity round @ 30 degrees | 9" |
| Capacity round @ 30 degrees w/overhead bundling | 6" |
| Blade size | 1-1/4" x 16' 11" |
| Blade drive | 7.5 HP, VFD |
| Machine voltage | 480V |
| Blade speeds | 65-385 SFM |
| Automatic multi-indexing | 60" |
| Coolant tank capacity | 30 gallons |
| Table height | 44" |
| Machine weight | 9,000 LBS |
| Machine dimensions | 120" x 188" x 112" |
